SURTRON 80D

Description

Key Features

• Operating Modes: Provides four distinct functions—CUT, BLEND, COAG, and MICRO—allowing adaptability to different surgical needs.

• Digital Interface: Equipped with an onboard microcontroller and digital display, ensuring consistent safety and reliability under various conditions.

• Safety Measures: Features patient/plate circuit monitoring, output power control, and self-diagnostic functions to maintain optimal safety standards.

• Underwater Cutting and Coagulation: Capable of performing procedures in wet environments, expanding its range of applications

Technical Data

• Maximum output power CUT
  80 W – 400 Ω
• Maximum output power BLEND
  60 W – 400 Ω
• Maximum output power COAG
  50 W – 400 Ω
• Maximum output power MICRO
  20 W – 600 Ω
• Working frequency 700 kHz
• Patient circuit F
• Selectable input voltage 115-230 VAC
• Main frequency 50-60 Hz
• Electrical input power: 280 VA
• Size WxHxD mm 190x85x239
• Weight 2,5 Kg

CONTROLS

• Patient/Plate circuit monitoring
• Output power monitoring
• Self-check control

SAFETY

• EN60601-1
• EN60601-1-2
• EN60601-2-2
• Clasificación eléctrica: I CF
• MDR 2017/745/UE Class: II b
